Min. Lòd:1 Piece/Pieces
Modèl Pa gen.: LQ150X1LW96
Rezolisyon ekspozisyon LQ150x1LW96 la se 1024 (RGB) × 768 (XGA), rapò aspè a se 4: 3 (lajè: wotè), ak piksèl yo ranje nan bann RGB vètikal. Gwosè a zòn ekspozisyon nan LQ150x1LW96 se 304.128 × 228.096 (W × H) mm, gwosè a vizib se 307.4 × 231.3 (W × H) mm, ak gwosè a ekstèn se 326.5 (W) × 253.5 (h) × 10.1 (d) mm. Matte fini, kouch difisil (3h), nèt pwa 950g (max.)
Ekleraj la adopte yon sous limyè kwen -kalite, tanperati opere li yo se -20 ~ 70 ° C, ak tanperati depo li yo se -25 ~ 70 ° C, ki se apwopriye pou Endistriyèl ak D 'medikal.
| brand | Sharp | Model name | LQ150X1LW96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 1500:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1(H×V×D)mm |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | work environment | Storage temperature: -25 to 70 °C Operation Temperature: -20 to 70 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins | ||
| supply voltage | 3.3V (Typ.) |
Q: Èske ou manifakti (faktori)?
Yon ： Wi, nou. Tou OEM/ODM sèvis ki disponib isit la.Welcome yo pataje lide ou avèk nou. Li nan plezi nou yo bay pi bon solisyon pou ou.
K ： Èske mwen ka achte yon echantiyon pou lòd mwen an?
A ： Wi, tanpri, ezite kontakte nou.
