Modèl Pa gen.: LQ150X1LG96
Tanperati k ap travay nan LQ150x1LG96 se 0 ~ 65 ° C, ak tanperati a depo se -30 ~ 70 ° C. Li se apwopriye pou aplikasyon pou endistriyèl, en deyò, jwèt. Tretman sifas la se ma, kouch difisil (3H), ak pwa a nèt nan pwodwi a se 950g (max.). An tèm de ekleraj, sous la limyè bò-kalite gen yon validite nan 30k èdtan.
Rezolisyon ekspozisyon LQ150X1LG96 la se 1024 (RGB) × 768 (XGA), rapò aspè a se 4: 3 (lajè: wotè), ak piksèl yo ranje nan bann RGB vètikal. Gwosè a zòn ekspozisyon nan LQ150x1LG96 se 304.128 × 228.096 (W × H) mm, gwosè a vizib se 307.2 × 231.1 (W × H) mm, ak gwosè a ekstèn se 326.5 (W) × 253.5 (h) × 10.1 (d) mm.
| brand | Sharp | Model name | LQ150X1LG96 |
| size | 15inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 [XGA] 85PPI | Pixel configuration | RGB vertical bar |
| Display Area | 304.128×228.096mm(H×V) | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 307.2×231.1mm(H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 1050cd/m²(Typ.)or customized | Outline dimension | 326.5×253.5×10.1 mm(H×V×D) |
| Viewing Angle | 80/80/60/80 (Typ.)(CR≥10) | work environment | Storage temperature: -30 to 70 °C Operation Temperature: 0 to 65 °C |
| Signal interface | LVDS (1 ch, 6/8-bit),erminal,20 pins |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
