Min. Lòd:1 Piece/Pieces
Modèl Pa gen.: LQ156M1LG21
LQ156M1LG21 a gen yon rezolisyon ekspozisyon nan 1920 (RGB) × 1080 (FHD), yon rapò aspè nan 16: 9 (lajè: wotè), ak piksèl yo ranje nan RGB bann vètikal.
Gwosè a zòn ekspozisyon nan LQ156M1LG21 se 344.16 × 193.59 (W × H) mm, gwosè a vizib se 349.0 × 198.4 (W × H) mm, gwosè a ekstèn se 370 × 217 (W × H) × 9.8 (d) mm, Tretman sifas fini ma, kouch difisil (3h), pwa nèt 950g (max.)
An tèm de ekleraj, se yon sous limyè limyè ki emèt limyè ki itilize, epi lavi sèvis la nan sous la limyè se 50k èdtan. Tanperati a opere nan LQ156M1LG21 a se 0 ~ 70 ° C, ak tanperati a depo se -30 ~ 70 ° C.
| brand | Sharp | Model name | LQ156M1LG21 |
| size | 15.6inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD | Pixel configuration | RGB vertical bar |
| Display Area | 344.16×193.59(H×V)mm | Surface treatment | Fog surface，Hard coating (3H) |
| Visual size | 349.0×198.4(H×V)mm | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 370×217×9.8(H*V*D) mm |
| Viewing Angle | 80/80/80/65 (Typ.)(CR≥10) | work environment | Storage temperature: 0 to 70 °C Operation Temperature: -30 to 70 °C |
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal |
|
|
| supply voltage | 3.3V (Typ.) |
|
|
