Min. Lòd:1 Piece/Pieces
UV215FHM-N10 se yon modil kristal likid 21.5-pous ak A-Si TFT-LCD teknoloji, rezolisyon an ekspozisyon se 1920 (RGB) × 1080 (FHD), rapò a aspè se 16: 9 (lajè: wotè), ak pixel la Adopte RGB ranje nan bann vètikal yo. Gwosè zòn ekspozisyon li a se 476.64 × 268.11 (w × h) mm, gwosè a vizib se 479.8 × 271.3 (w × h) mm, ak gwosè a aparans se 495.6 (w) × 292.2 (h) × 11.2 (d) mm.
Trete kòm ma (brouyar 25%), kouch difisil (3H), tanperati k ap travay li yo se -20 ~ 80 ° C, ak tanperati depo li yo se -30 ~ 85 ° C. Pou signalisation dijital. Sous limyè kwen-kalite, lavi a sèvis nan sous la limyè se 30k èdtan, lè l sèvi avèk LVDS (2 CH, 8-ti jan) koòdone siyal, yon total de 30 broch, lè l sèvi avèk koneksyon tèminal, vòltaj la kondwi se 5.0v (tip.) .
Q: Èske gen nenpòt lòt gwosè oswa spesifikasyon ka chwazi?
Yon ： Si ou bezwen diferan gwosè oswa espesifikasyon, nou pral bay konplo ki pi apwopriye dapre kondisyon ou yo.
K: Ki sèvis pre-sale ou ak apre-sale?
Yon ： An tèm de pre-lavant sèvis, nou gen yon ekip lavant pwofesyonèl ak ekip teknik, ki moun ki vle reponn kesyon ou yo nan lespas 24 èdtan.Pou apre-lavant sèvis, nou ka enstwi ki jan yo enstale, itilize ak ranplase modil domaje.
K: Ki jan nou ka kenbe yon bon relasyon biznis alontèm?
Yon ： Nou kenbe bon jan kalite bon ak pri konpetitif asire ke kliyan benefisye; Nou respekte chak kliyan epi trete yo kòm zanmi. Kèlkeswa kote yo soti, nou sensèman fè biznis ak yo epi fè zanmi.
| brand | BOE | Model name | UV215FHM-N10 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -30 to 85 °C Operation Temperature: -20 to 80 °C |
Paramèt nan modèl la menm gwosè
| brand | BOE | Model name | DV215FHM-R01 |
| size | 21.5 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1920(RGB)×1080 FHD 102PPI | Pixel configuration | RGB vertical bar |
| Display Area | 476.64×268.11(H×V)mm | Surface treatment | Fog surface(Haze 25%)，Hard coating (3H) |
| Open zone | 479.8×271.3(H×V)mm | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 495.6×292.2×11.2mm(H×V×D) |
| Viewing Angle | 89/89/89/89(Typ.)(CR≥10) | ||
| Signal interface | 30 pins LVDS (2 ch, 8-bit),erminal | ||
| work environment | Storage temperature: -20 to 85 °C Operation Temperature: -20 to 85 °C |
Tags cho: 21.5 "BOE UV215FHM-N10 TFT Modil panèl LCD, Lachin, faktori, bon mache, pri, Customized, sitasyon , panèl pou televizyon deyò
