Atribi pwodwi yo

Modèl Pa gen.: EV101WXM-N81

Anbalaj & akouchman

Vann Inite:

Piece/Pieces

Pwodwi Entwodiksyon

EV101WXM-N81 se yon modil LCD 10.1-pous lè l sèvi avèk A-Si TFT-LCD teknoloji. Li se ekipe ak WLED ekleraj, ki gen ladan dirije kondwi chofè ekleraj, pa gen okenn manyen. Rezolisyon ekspozisyon se 1280 (RGB) × 800 (WXGA), rapò aspè se 16:10 (lajè: wotè), ak piksèl yo ranje nan RGB bann vètikal. Gwosè zòn ekspozisyon li yo se 216.96 × 135.6 (lajè × wotè) mm, gwosè vizyèl se 219.4 × 138.0 (lajè × wotè) mm, gwosè ekstèn se 233.2 × 152.9 (lajè × wotè) × 10.4 (epesè) mm, pwodwi pwa nèt 505g (Tip.). An tèm de ekleraj, pwodwi sa a sèvi ak yon bò kote antre nan sous limyè ak yon lavi nan 50k èdtan, ki gen ladan dirije chofè. EV101WXM-N81 sèvi ak LVDS (1 CH, 8-ti jan) koòdone siyal, yon total de 20 broch, sèvi ak koneksyon tèminal, kondwi ekran vòltaj se 3.3V (tip.). Tipik li yo vètikal rafrechir to FV se 60Hz. Li opere nan -20 ° C a 70 ° C ak magazen nan -30 ° C a 80 ° C. Baze sou blan li yo ki ap dirije ekleraj, lavi a se plis pase 50,000 èdtan.

R-Star soti nan Shenzhen, Lachin, nou se yon manifakti pwofesyonèl nan segondè fen mete aksan Highlight LCD, endistriyèl mete aksan sou TFT-LCD, transparan LCD ak ekspozisyon ankadreman, doub-sided LCD, wo-limyè doub-sided LCD ak lòt-wo fen LCD panèl. Nan ti bout tan, k ap monte gen plis pase 5 ane nan gwo klète ekleraj eksperyans teknoloji modil, 8 ane nan gwo konsepsyon modil TFT, rechèch ak devlopman, kapasite pwodiksyon, 10 ane nan-wo kalite chèn materyèl anvan tout koreksyon.

brand	BOE	Model name	EV101WXM-N81
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800, WXGA, 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96×135.6(H×V)mm	Surface treatment	/
Visual size	233.2×152.9×10.4(H×V×D) mm	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	233.2×152.9×10.4(H×V×D)mm
Viewing Angle	85/85/85/85 (Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 20 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

Modèl la menm gwosè ak paramèt yo jan sa a

brand	BOE	Model name	EV101WUM-N20
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1920(RGB)×1200, WUXGA, 224PPI	Pixel configuration	RGB vertical bar
Display Area	216.806×135.504mm(H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	600cd/m²(Typ.)or customized	Outline dimension	229.45×149.22(H×V)mm
Viewing Angle	80/80/80/80(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 45 pins
work environment	Storage temperature: -25 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	AT101WSM-N11-58P0
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1024(RGB)×600, WSVGA, 117PPI	Pixel configuration	RGB vertical bar
Display Area	222.72×125.28mm(H×V)	Surface treatment	Fog surface，Hard coating (3H)
Visual size	226×128.6(H×V)mm	Contrast Ratio	500:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	235×144.9×5.44mm(H×V×D)
Viewing Angle	80/80/60/70(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 6/8-bit) , 60 pins , FPC
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

brand	BOE	Model name	EV101WXM-N82
size	10.1 inch	Screen type	a-Si TFT-LCD,LCD module
resolution ratio	1280(RGB)×800 [WXGA] 149PPI	Pixel configuration	RGB vertical bar
Display Area	216.96 × 135.6 mm (H×V)	Surface treatment	/
Visual size	/	Contrast Ratio	900:1 (Typ.) (TM)
Brightness(cd/m²)	500cd/m²(Typ.)or customized	Outline dimension	228.6 ×149.2×6 mm (H×V×D)
Viewing Angle	85/85/85/85(Typ.)(CR≥10)
Signal interface	LVDS (1 ch, 8-bit) ,erminal, 40 pins
work environment	Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C

10.1 pous panèl
