Min. Lòd:1 Piece/Pieces
Modèl Pa gen.: BA104S01-100
BA104S01-100 se yon pwodwi modil LCD 10.4-pous lanse pa BoE Teknoloji Group co, Ltd. (BOE) Sèvi ak A-Si TFT-LCD teknoloji. Li se ekipe ak WLED ekleraj, pa gen okenn kondwi ekleraj ak pa gen okenn manyen. BA104S01-100 Montre yon rezolisyon nan 800 (RGB) × 600 (SVGA), yon rapò aspè nan 4: 3 (lajè: wotè), ak piksèl yo yo ranje nan bann RGB vètikal, dapre spesifikasyon nan pwodwi ak vèsyon No. Rev Rev .1 pibliye pa BOE sou Desanm 12, 2014. Gwosè zòn ekspozisyon li yo se 211.2 × 158.4 (lajè × wotè) mm, gwosè vizyèl se 215.0 × 162.0 (lajè × wotè) mm, gwosè aparans se 236 × 176.9 (lajè × wotè) wotè) × 5.9 (epesè) mm, tretman sifas ki klè, pwodwi nèt pwa se 288g (typ.). Ekleraj sa a pwodwi sèvi ak yon 6S6P WLED bò antre limyè sous (tèt), lavi sa a ki nan sous la limyè se 50k èdtan, pa gen okenn kondwi ekleraj. BA104S01-100 Adopte LVDS (1 CH, 6/8-ti jan) koòdone siyal, yon total de 20 broch, adopte koneksyon tèminal, kondwi ekran vòltaj se 3.3V (tip.). Tipik li yo vètikal rafrechir to FV se 60Hz. Li opere nan -20 ° C a 70 ° C ak magazen nan -30 ° C a 80 ° C. Modèl sa a rekòmande pou itilize nan D 'endistriyèl ak medikal akòz blan li yo ki ap dirije ekleraj, plis pase 50,000 èdtan nan lavi, baskile tèminal, 6/8 Bits nan echèl si ou vle gri, ak lòt karakteristik.
| brand | BOE | Model name | BA104S01-100 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 800(RGB)×600 [SVGA] 96PPI | Pixel configuration | RGB vertical bar |
| Display Area | 211.2×158.4 mm (H×V) | Surface treatment | Clear |
| Visual size | 215.0×162.0 mm (H×V) | Contrast Ratio | 800:1 (Typ.) (TM) |
| Brightness(cd/m²) | 500cd/m²(Typ.)or customized | Outline dimension | 236×176.9×5.9 mm (H×V×D) |
| Viewing Angle | 70/70/60/70 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -30 to 80 °C Operation Temperature: -20 to 70 °C |
Sa ki anba la yo se modèl yo menm gwosè ak paramèt
| brand | BOE | Model name | AV104X0M-N10 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | 215.4 × 161.8 (H×V) mm | Contrast Ratio | 1100:1 (Typ.) (TM) |
| Brightness(cd/m²) | 600cd/m²(Typ.)or customized | Outline dimension | 230 × 180.2(H×V) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 6/8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -40 to 95 °C Operation Temperature: -30 to 85 °C |
| brand | BOE | Model name | TDA104-001V02 |
| size | 10.4 inch | Screen type | a-Si TFT-LCD,LCD module |
| resolution ratio | 1024(RGB)×768 (XGA) 123PPI | Pixel configuration | RGB vertical bar |
| Display Area | 210.4 × 157.8 (H×V) mm | Surface treatment | / |
| Visual size | / | Contrast Ratio | 1000:1 (Typ.) (TM) |
| Brightness(cd/m²) | 900cd/m²(Typ.)or customized | Outline dimension | 235×173×10.5mm(H×V×D) |
| Viewing Angle | 85/85/85/85 (Typ.)(CR≥10) | ||
| Signal interface | LVDS (1 ch, 8-bit) ,erminal, 20 pins | ||
| work environment | Storage temperature: -55 to 85 °C Operation Temperature: -40 to 80 °C |
Tags cho: BOE BA104S01-100 Kléorasyon 500NITS TFT-LCD panèl, Lachin, faktori, bon mache, pri, Customized, sitasyon pi ba, fè fas a LCD, ti gwosè ekran LCD, Windows ekspozisyon, ekran ekspozisyon 65 pous, HD ekran deyò, 19inch LCD, Ekran LCD pou deyò , LCD panèl, LCD modil, ekspozisyon segondè klète.
