Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Shenzhen Risingstar Outdoor High Light LCD Co., Ltd
Brand: Risingstar
Pwodiktivite: 189k
Kote orijin: Shenzhen
Sètifika: ISO9001/CE/ROSH/UL/FCC
15.4 "High klète TFT LCD panèl, sa a panèl LCD segondè klète pa 1000 nits, Sunshine lizib. Sa a segondè klète modil LCD ak Chimei Innolux orijinal panèl.with bò-an ki ap dirije ekleraj pou klète inifòm.
Chak ekran limyè RisingStar Outdoor a se endividyèlman koulè kalibre nan estanda a koulè D65 (6500K) CIE; 500-1000 nits ka chwazi, inifòmite klète plis pase 90%.
15.4 "High klète TFT LCD panèl, li se ekipe ak WLED ekleraj, kondwi ekleraj ak chofè ki ap dirije, tanperati a opere: -30 ~ 80 ° C, tanperati a depo: -30 ~ 80 ° C, ak rezistans a Vibration se 1.5g (14.7m /s²).
15.4 "Segondè klète se lajman ki itilize nan ekspozisyon kontwòl endistriyèl, kat klas elektwonik, nouvo enèji chaje pil, eksprime kabinèt, deyò panno kontwòl pòtatif, machin ekran koutim ,, elatriye.
| Product size | 15.4 inch | Type | a-Si TFT-LCD |
| Pixel Format | 1280(RGB)×800[WUXGA] 98PPI | Configuration | RGB Vertical Stripe |
| Active Area | 334.5(H)×210.3(V) mm | Outline Dim. | 352(H)×230(V) ×9.5(D) mm |
| Viewing Angle | 80/80/70/70 (Min.)(CR≥10) | Treatment | Glare , Hard coating (3H) |
| Luminance | 1000 cd/m² (Typ.) | Contrast Ratio | 700:1 (Typ.) (TM) |
| View Direction | Symmetry | Response Time | 5/11(Typ.)(Tr/Td) |
| Support Color | 16.2M 56% NTSC | Light Source | WLED , 50K hours , With LED Driver |
| Weight | 880g | Designed For | Outdoor High Brightness Automotive Display |
| Frequency | 60Hz | Touch Panel | Without |
| Interface Type | LVDS(1 ch,6/8-bit) , 30pins | ||
| Power Supply | 3.3V (Typ.) | ||
| Environment | Operating Temperature: -30 ~ 80 °C ; Storage Temperature: -30 ~ 80 °C |
